Best Practice Guide on establishing nutrient concentrations to support good ecological status
Geoff Phillips, Martyn Kelly, Wera Leujak, Fuensanta Salas, Heliana Teixeira, Anne Lyche Solheim, Gary Free, Gabor Varbiro
Final version following testing at Bucharest workshop November 2018
Summary
- 1. High concentrations of inorganic nutrients are a major factor contributing to the failure of many water bodies to achieve Good Ecological Status and Member States need to determine levels appropriate to their own territories.
- 2. This report describes statistical methods for determining appropriate concentrations for supporting ecological status. These statistical methods need to be set in a broader framework that also encompasses chemical, ecological and regulatory aspects relevant to the type of water body under consideration.
- 3. Three approaches to setting these threshold concentrations are included. These are: • Regression analysis, using a continuous relationship between EQR and nutrient concentration • Categorical analysis, using the distribution of nutrient concentration within biological classes • Minimisation of mis-match of classifications for biology and nutrients
- 4. The choice of method depends upon a number of factors, including the length of the gradient that available datasets cover and the statistical strength of the relationship between the explanatory and response variables. In some cases, Member States may be better able to achieve the statistical prerequisites for methods by joining forces with neighbours who share similar water body types.
- 5. Excel and R-based statistical “toolkits” are provided in order to make calculation of threshold concentrations more straightforward.
- 6. Options for situations where none of these methods are appropriate are also described.
- 7. Finally, some practical issues associated with the use of these threshold concentrations for regulation are discussed.
Disclaimer
This application has been developed through a collaborative framework (the Common Implementation Strategy (CIS)) involving the Member States, EFTA countries, and other stakeholders including the European Commission. The document is a working draft and does not necessarily represent the official, formal position of any of the partners.
To the extent that the European Commission's services provided input to this technical document, such input does not necessarily reflect the views of the European Commission.
Neither the European Commission nor any other CIS partners are responsible for the use that any third party might make of the information contained in this document.
The technical document is intended to facilitate the implementation of Directive 2000/60/EC and is not legally binding. Any authoritative reading of the law should only be derived from Directive 2000/60/EC itself and other applicable legal texts or principles. Only the Court of Justice of the European Union is competent to authoritatively interpret Union legislation.
Reference
Please reference the use of this application in any publications as
Gabor Varbiro, Heliana Teixeira, Martyn Kelly and Geoff Phillips (2018)A Shiny application of a statistical toolkit to assist with the development of nutrient concentrations that would support good ecological status for the Water Framework Directive. Phillips, G., Kelly, M., Teixeira, H., Salas Herrero, M.F., Free, G., Leujak, W., Lyche Solheim, A., Varbiro, G. and Poikane, S., Best practice for establishing nutrient concentrations to support good ecological status, EUR 29329 EN, Publications Office of the European Union, Luxembourg, 2018, ISBN 978-92-79-92907-6, doi:10.2760/123549, JRC112667.
Best Practice Guide How-to
First Import the file or use the sample dataset. Don't forget to use the proper decimal and separation symbols.
The content of the data / boxplots etc can be found in the Check data tab
You can adjust the EQR boundaries, the application recalculate all statistic with the new values
Before proceeding with the Toolkit you can select outliers to exlude from the analyses
You can adjust the Nutrient boundaries for linear and mismatch methods check the R2 to achieve the best correlation, the application recalculate all statistic with the new values.
Best Practice Guide Analyses guides
Measure (abbreviation)
Measures of classification accuracy used to compare two binary classifications
Import
Select the proper separator and decimal settings before loading the data
*In order to test the application ....
Content of the datafile
Variable selection
In this section it is possible to select the variables to be used by the toolkit. Please check if it is numerical variable.
Plot_EQR Outliers
Before proceeding with the Toolkit's calculation steps you can select outliers to exlude from the analyses. Blue dots : sample points, Red dots: outliers.
* by clickling on the sampling points you can select or deselect them...
Sample points excluded
Visualise Nutrient range
The toolkit allows three regression models to be fitted to the linear portion of the data:
- a type II regression; assumes equal uncertainty in measurement of both EQR and nutrient (slope between the two OLS regressions).
- an Ordinary Least Squares (OLS) regression of EQR v nutrient concentration; assumes all uncertainty is in measurement of the EQR (underestimate of slope);
- an OLS regression of nutrient v EQR; assumes all uncertainty lies in measurement of nutrient concentrations (overestimate of slope);
It is important to stress that selecting the segment of data to be used will have a significant influence on the slope of the linear models and thus the predicted boundary values and is to an extent a subjective decision, albeit guided by the gam and segmented regression models.
Ranged major axis regression EQR vs. Nutrient
Figure A Relationship between EQR and Nutrient concentration in test data set showing RMA type II regression. Predicted high/good boundary values shown.
Figure B Relationship between EQR and Nutrient concentration in test data set showing RMA type II regression. Predicted good/moderate boundary values shown.
Linear method Confusion matrix metrics
Confusion matrix metrics
Linear methods results
Data.frame contains the following values as columns: Model, r2, the number of observations used N, slope, intercept, predicted good/moderate boundary GM, lower and upper estimates of good/moderate boundaries GML GMU, the high/good boundary HG, lower and upper estimates of high/good boundaries HGL HGU. Rows are results for Model 1, Model 3 and Model 2.
OLS Regression of EQR on Nutrient
Figure C Relationship between EQR and Nutrient concentration in test data set showing OLS regression of EQR vs Nutrient. Predicted good/moderate boundary values shown.
OLS Regression of Nutrient on EQR
Figure D Relationship between EQR and Nutrient concentration in test data set showing OLS regression of Nutrient on EQR (inverted to plot on same scales). Predicted good/moderate boundary values shown.
Boxplot methods results
Boxplot summary table
Boxplot summary
If the differences between the nutrient concentrations in adjacent classes are not significant, treat quantiles with extreme caution. On the Boxplots significance indicated by Wilcoxon signed rank test.
Wedge shape detection
Test on variance /f.test/
In this test the 'EQR' is being tested across the 1st and 5th quantile categories generated based on stressor using a variance test (var.test) within this subset of the data. The resulting p-value from this test indicates whether there is a statistically significant difference in the variance in the EQR in the two quantile categories. If the p-value is less than the 0.05 significance level then there is evidence of heteroscedasticity which could mean wedge shape distribution.
Breusch-Pagan test
The Breusch-Pagan test statistic is used to test for heteroscedasticity in a linear regression model. If the test statistic is significant (i.e., the p-value is less than the 0.05 significance level), we can reject the null hypothesis and conclude that there is evidence of heteroscedasticity whihc could mean wedge shape distribution.
Wedge shape plot
Standard Residual plot
Linear Quantile regression results
Linear quantiles
Scatterplot of Nutrient vs. EQR with quantile regression lines for the 10th(grey), 25th(red), 50th(black), 75th(blue), and 90th(grey) percentiles.
* The linear quantiles restricted for the data range choosen with the range sliders in the Linear methods menu.Quantile table
Quantile method Confusion matrix metrics
Additive Quantile regression results
* The additive quantiles plot
Scatterplot of Nutrient vs. EQR with quantile regression lines for the 25th(red), 50th(green), 75th(red)
Additive Quantile Confusion matrix metrics
* The additive quantiles Confusion plot * The additive quantiles Confusion table
Logistic method result
To fit a segmented regression, it is necessary to estimate the break points. In the test data set curvature is not that marked, thus it is best to start with a single break point. Other data sets may clearly require 2 break points and to accommodate these two different functions have been provided.
Figure A- 13 Scatter plot showing relationship between EQR and TP with fitted GAM model, with segmented regression lines. a) with two estimated break points b) with single estimated break point
Binary logistic models
Parameters for Binary logistic methods
The selection is aviable only if the dataset contain EQC / Biological Class values/
*The analysis takes a bit of time so click on this button wait a bit till the results appears....
Table 1
The following table shows predicted boundary values, from binary logistic models together with key measures from their confusion matrix. The most appropriate boundary, based on the optimum criteria is marked as orange.
Table 2
The most appropriate boundary is shown here :
Table 3
The descriptive metrics of the model
Binary Logistic methods results
Fig1a
a) scatter plot with model fit and predicted boundary concentrations for the stressor threshold determined by optimal decision.
Fig1c
c) Boxplots showing range of stressor for samples classified by biota. (*dotted lines show boundary values.)
Fig1b
b) Confusion matrix showing number of true and false records and measure.
Fig1d
d) Boxplots showing range of EQR for samples classified using the predicted stressor boundary. (*dotted lines show boundary values.)
Explanatory graphs
Binary Logistic methods results
Figure a: Results of fitting GLM to scatter plot with model fit and predicted boundary concentrations (SE); b)confusion matrix showing number of true and false records and measures, c) boxplots showing range of stressor for waterbodies classified by BQE. d) boxplots showing range of EQR for waterbodies classified using the predicted stressor boundary. dotted lines show boundary values
Figure b: Density distribution and box plots showing the range of stressor concentration in sites classified biologically into good or better and moderate or poor status. Data are synthesised to illustrate a good separation of the stressor concentration.
Lineplot
Binary Logistic methods Lineplots
Change in measures used for assessing confusion matrix, with five possible cut-points marked:
a) max CCR,
b) max kappa,
c) FNR=FPR (the Tool Kit MisMatch Method),
d) commission = 0.2,
e) cross-over commission/omission,
Stressor Boundary Tester
To test the boundary you can adjust the slider to the desired value, Then the confusion matrix is generated based on the new values. The same true for adjusting the EQR on the sidebar.
Confusion matrix metrics
Summary of the methods
Download the report of the analyses
The toolkit can generate a report which includes the figures and tables produced by the analyses. In order to generate all figures and tables you need to go through(click) all analytical steps.
Render html report
